Product Name:
Wall-Mount Rack 19" Model
Description:
Measuring 6u~15u spaces high and 21" deep, the SBX 7 and SBX 10 wall mount cabinets offer an economical solution to those seeking a wall-mount rack for smaller systems. The fully welded construction utilizes 18-gauge steel, incorporates a locking front door which swings open a full 180º on a virtually indestructible hinge,and includes a removable backpan for simple installation and easy access to connections.
Ventilation slots at the top of each side provide superior cooling, while a deep rail-to-door clearance ratio provides flexibility not found in flush-mount door designs. electrical knockouts at top, bottom, and rear, and a black textured powder coat finish.
Mat. : Steel
Features:
- Welding frame construction, steady and dependable
- Wall-mounted installing, divided cabinet body construction, cabinet body can shake out 120 ° , convenient for operation
- Convenient and quick wall-mounted installing method
- 19" standard installing
- Quick opening side door, can add a side door lock, convenient for installing and maintaining
- Can from top and bottom going wire at the same time
- Can add 120mm fan
- The front door can open over 180 °
- Loading: Resting loading 60Kg
- Protection grade: IP20
- Main material: SPCC High-quality cold roll steel , Thickness: 2.0 mm for mounting rails and 1.2 mm for others
- The surface finish: Degreasing, acidification, phosphoric , static electricity ,power coat
Specification:
Order Code Capacity Width Depth JDW 6506 6U 600 550 JDW 6509 9U 600 550 JDW 6512 12U 600 550 JDW 6515 15U 600 550 JDW 6518 18U 600 550
Safety Approval:
This is the detailed information for Wall-Mount Rack 19" Model, JDW Series. The information includes model, name, description and specification for Wall-Mount Rack 19" Model, JDW Series. Related Keywords : Wall Mount Rack,Wall Mount,Rack
