J2 Series , 19" Cabinet Rack

19" Cabinet Rack

J2 Series is a rock solid server rack cabinet frame that offers 4 Post Vendor Neutral Mounting Rails adjustable to accommodate servers up to 36" deep. Also included are 2- Auxiliary Vertical Rails (required for optional shelf mounting). The heavy-duty steel construction of this server rack is made to support heavy servers and peripherals. Our unique cable trunk provides efficient vertical cable routing that is neatly secured with our Quick Release Cable Latches. Optional shelves, keyboard turntable and vertical power strip are also available.

The J2 Server Cabinet and netwok rack series includes a grounding/bonding stud in the base of rack which facilitates proper grounding and bonding of electronic equipment, as per NEBS and NEC standards.

The server cabinet rail brackets are pre-punched for built-in cable management. Multiple lacing points and slotted rail brackets add cable management convenience. The J2 server cabinet/NETWORK RACK has removable rear plates which allow cable bundles to be easily passed over or under the J2's standard key-locking rear door.

This server cabinet is modular in design and you choose from three types of front doors, multiple rack rails, different fan tops, etc.

The J2 Series is a lighter weight, economy server cabinet and not suitable for all applications.


Network/Server Rack
Mat. : Steel

- Steel Frame
- Vented front door and rear door accelerate the convection inside enclosure
- Smoked Plexiglas front door, color is optional
- Removable side panels
- Leveling feet or castors, Max. Static load 800Kg, Max. Dynamic load 350Kg

Order Code	Capacity	Width	Depth
J26641	41U	600	600
J26841		600	800
J26636	36U	600	600
J26631	31U	600	600
J26621	21U	600	600
J26821		600	800
